A simple approach to a dog breed classifier with ResNet

deep learningcnnkeras
sad looking Pug inside a blanket

Photo by Matthew Henry on Unsplash

“The dog is a gentleman; I hope to go to his heaven not man’s.” — Mark Twain

There are many different dog breeds, and for some people it’s hard to differentiate between, say, an Alaskan Malamute and a Siberian Husky — with over 340 breeds recognized by the Fédération Cynologique Internationale.

That’s why we want to use deep learning to create a classifier for this task. We’ll use Convolutional Neural Networks (CNNs), which make the assumption that the input is an image and that certain aspects of it are encoded by the network’s architecture.

Besides creating a dog classifier, we’ll also use it to classify human faces and their look-alike dog breed. The approach is structured into five simple steps.

Step 1: Downloading and importing the dataset

The first dataset consists of 13,233 human images. The second dataset consists of 8,351 dog images.

After downloading and unzipping both into your data folder, we create a function to load the dataset and build train, valid and test files plus targets:

def load_dataset(path):
    data = load_files(path)
    dog_files = np.array(data['filenames'])
    dog_targets = np_utils.to_categorical(np.array(data['target']), 133)
    return dog_files, dog_targets

# load train, test, and validation datasets
train_files, train_targets = load_dataset('path/to/yourdata/dog_images/train')
valid_files, valid_targets = load_dataset('path/to/yourdata/dog_images/valid')
test_files, test_targets = load_dataset('path/to/yourdata/dog_images/test')

This gives us 6,680 training images, 835 validation images and 836 test images across 133 dog categories — an 80/10/10 split.

Step 2: Face and dog detectors with OpenCV

OpenCV provides hundreds of computer vision algorithms. We use the OpenCV Haar feature-based cascade classifiers to detect human faces, with the pre-trained frontal face cascade from the OpenCV repo.

import cv2

# extract pre-trained face detector
face_cascade = cv2.CascadeClassifier(
    'path_to_haarcascade_xml/haarcascade_frontalface_alt.xml'
)

# returns "True" if face is detected in image stored at img_path
def face_detector(img_path):
    img = cv2.imread(img_path)
    gray = cv2.cvtColor(img, cv2.COLOR_BGR2GRAY)
    faces = face_cascade.detectMultiScale(gray)
    return len(faces) > 0

For the dog detector we use ResNet-50, a pre-trained image classification model:

from keras.applications.resnet50 import ResNet50

# define ResNet50 model
ResNet50_model = ResNet50(weights='imagenet')

def dog_detector(img_path):
    prediction = ResNet50_predict_labels(img_path)
    return ((prediction <= 268) & (prediction >= 151))

The dog detector outputs a label from the ResNet50 dictionary; labels 151–268 are dog categories, from ‘Border collie’ up to ‘Walker foxhound’.

Step 3: A CNN from scratch

To get a better understanding of how a CNN works, we first create one from scratch. The first step is transforming our images into tensors:

def path_to_tensor(img_path):
    # loads RGB image as PIL.Image.Image type
    img = image.load_img(img_path, target_size=(224, 224))
    # convert PIL.Image.Image type to 3D tensor with shape (224, 224, 3)
    x = image.img_to_array(img)
    # convert 3D tensor to 4D tensor with shape (1, 224, 224, 3)
    return np.expand_dims(x, axis=0)

def paths_to_tensor(img_paths):
    list_of_tensors = [path_to_tensor(img_path) for img_path in tqdm(img_paths)]
    return np.vstack(list_of_tensors)

# pre-process the data for Keras
train_tensors = paths_to_tensor(train_files).astype('float32')/255
valid_tensors = paths_to_tensor(valid_files).astype('float32')/255
test_tensors = paths_to_tensor(test_files).astype('float32')/255

Dividing by 255 scales the pictures. With preprocessing done, we create our CNN:

model = Sequential()
model.add(Conv2D(filters=16, kernel_size=2,
                 input_shape=(224, 224, 3), activation='relu'))
model.add(MaxPooling2D(pool_size=2, data_format='channels_last'))
model.add(Conv2D(filters=32, kernel_size=2, activation='relu'))
model.add(MaxPooling2D(pool_size=2, data_format='channels_last'))
model.add(Conv2D(filters=64, kernel_size=2, activation='relu'))
model.add(MaxPooling2D(pool_size=2, data_format='channels_last'))
model.add(GlobalAveragePooling2D())
model.compile(optimizer='rmsprop', loss='categorical_crossentropy',
              metrics=['accuracy'])

A very simple model: ReLU activations on each layer with MaxPooling, cross-entropy loss, rmsprop optimizer. Trained for 25 epochs, it reaches 1.19% accuracy — better than random guessing across 133 breeds, but that’s about it.

Step 4: Transfer learning with ResNet

1.19% accuracy isn’t production-ready, so we use ResNet and optimize it on our image dataset:

# Create the model
Resnet50_model = Sequential()
Resnet50_model.add(GlobalAveragePooling2D(
    input_shape=(train_ResNet_50.shape[1:])))
Resnet50_model.add(Dense(133, activation='softmax'))
Resnet50_model.summary()

Compile and train:

Resnet50_model.compile(loss='categorical_crossentropy', optimizer='rmsprop')

checkpointer = ModelCheckpoint(
    filepath='saved_models/weights.best.Resnet50.hdf5',
    verbose=1, save_best_only=True)
Resnet50_model.fit(train_ResNet_50, train_targets,
                   validation_data=(valid_ResNet_50, valid_targets),
                   epochs=20, batch_size=20, callbacks=[checkpointer],
                   verbose=1)

After training and loading the best model we reach a test accuracy of 81.56%.

Step 5: The dog identification app

def dog_identification_app(img_path):
    display(Image(img_path, width=200, height=200))
    breed = resnet50_prediction_breed(img_path)
    if dog_detector(img_path):
        print("Hello, dog! You look like a {}\n".format(breed))
    elif face_detector(img_path):
        print("Hello, human! You look like a {}\n".format(breed))
    else:
        print("Uhmmm you are not a dog or a human! "
              "Can you please try another picture? THANKS")

The input image is displayed first, then checked by the dog detector. If it’s neither a dog nor a human:

Uhmmm you are not a dog or a human! Can you please try another picture? THANKS

Conclusion and outlook

Training a CNN from scratch can be done in minutes to hours but likely won’t satisfy our needs. For most use cases — like a dog classifier — transfer learning is enough.

This was a fun project: building a CNN from scratch and then a Keras architecture on top of it for the actual classifier. It performs well when the parameters are right and the breed is in the classifier.

Some possible improvements:

  • The input image needs to show the front of a face; other face detection XMLs from OpenCV could improve this
  • Better preprocessing with transformers
  • Options for other look-alike animals (cats, etc.)
  • A simple web app with Flask

There’s also an approach with PyTorch and a more complex architecture in my GitHub repo.

All steps are in the project repository. Both datasets are from Udacity.

Thanks for reading!
